The right solution for every requirement
Products made of oxide ceramics for sample preparation and material analysis in laboratories
DEGUSSIT AL23 oxide ceramic crucibles and combustion trays are used for high-temperature analysis of materials in industrial and academic laboratories. Kyocera offers a wide range of standardised sizes for ceramic crucibles, combustion boats and annealing trays which can be found in our catalog and in the standard product catalogue in our download section. If you are looking for special shape ceramic laboratory utensils, just send us an enquiry with your part drawing.
The high purity of our alumina ensures chemical stability and chemical inertia at high temperatures together with high dimensional stability. Our high-pressure pressing method ensures the homogeneous microstructure and accuracy of shape of these ceramic laboratory ware. The dense sintered surface of DEGUSSIT oxide ceramics is extremely resistant to highly aggressive metal or glass melts. Our DEGUSSIT AL23 material is suitable for ultra-high vacuum applications thanks to its no porosity structure so it can be used in wide spectrum of research environments. The low SiO2 content in DEGUSSIT materials helps to achieve the widely recognized and impressive corrosion resistance, significantly extending the service life of our ceramic crucibles and laboratory trays. In cooperation with our customers, we can adapt the dimensions and geometries of the parts to their specific process requirements.
You are interested in our products or have a specific project enquiry?
Cylindrical crucibles
Cylindrical crucibles made of technical ceramics resist to high temperatures up to 1950°C and are chemically inert.
Our standard product range
| Article number | ØD | Ød | W | Volume |
| 201-11010-0150 | 10 mm | 8 mm | 15 mm | 0.7 ml |
| 201-11020-0300 | 20 mm | 16 mm | 30 mm | 6 ml |
| 201-11030-0400 | 30 mm | 26 mm | 40 mm | 20 ml |
| 201-11035-0500 | 35 mm | 30 mm | 50 mm | 40 ml |
| 201-11040-0600 | 40 mm | 36 mm | 60 mm | 60 ml |
| 201-11050-0750 | 50 mm | 44 mm | 75 mm | 110 ml |
| 201-11065-1000 | 65 mm | 55 mm | 100 mm | 225 ml |
| 201-11085-1500 | 85 mm | 73 mm | 150 mm | 600 ml |
| 201-11110-1500 | 110 mm | 100 mm | 150 mm | 1100 ml |
| Article number | ØD | Ød | W | Volume |
| 201-21020-0300 | 20 mm | 16 mm | 30 mm | 6 ml |
| 201-21030-0400 | 30 mm | 26 mm | 40 mm | 20 ml |
| 201-21035-0500 | 35 mm | 30 mm | 50 mm | 40 ml |
| 201-21040-0600 | 40 mm | 36 mm | 60 mm | 60 ml |
| 201-21050-0750 | 50 mm | 44 mm | 75 mm | 110 ml |
| 201-21065-1000 | 65 mm | 55 mm | 100 mm | 225 ml |
| 201-21085-1500 | 85 mm | 73 mm | 150 mm | 600 ml |
| Article number | ØD | Ød | W | Volume |
| 201-22120-2000 | 120 mm | 100 mm | 200 mm | 1500 ml |
| 201-22145-1600 | 145 mm | 125 mm | 160 mm | 1760 ml |
| Article number | ØD | Ød | W | Volume |
| 201-56010-0150 | 10 mm | 8 mm | 15 mm | 0.7 ml |
| 201-56020-0300 | 20 mm | 16 mm | 30 mm | 6 ml |
| 201-56030-0400 | 30 mm | 26 mm | 40 mm | 20 ml |
| 201-56035-0500 | 35 mm | 30 mm | 50 mm | 40 ml |
| 201-56040-0600 | 40 mm | 36 mm | 60 mm | 60 ml |
| 201-56050-0750 | 50 mm | 44 mm | 75 mm | 110 ml |
| 201-56065-1000 | 65 mm | 55 mm | 100 mm | 225 ml |
| 201-56085-1500 | 85 mm | 73 mm | 150 mm | 600 ml |
High-form conical crucibles
High conical crucibles are characterised by high dimensional stability and resistance to low and high temperatures.
Our standard product range
| Article number | ØD | Ød | D3 | height | Volume |
| 202-11020-0250 | 20 mm | 17 mm | 11 mm | 25 mm | 3 ml |
| 202-11025-0300 | 25 mm | 21 mm | 13 mm | 30 mm | 6 ml |
| 202-11030-0380 | 30 mm | 26 mm | 15 mm | 38 mm | 12 ml |
| 202-11035-0450 | 35 mm | 31 mm | 18 mm | 45 mm | 19 ml |
| 202-11045-0550 | 45 mm | 40 mm | 22 mm | 55 mm | 37 ml |
| 202-11060-0650 | 60 mm | 53 mm | 30 mm | 65 mm | 76 ml |
| 202-11073-0900 | 73 mm | 67 mm | 35 mm | 90 mm | 190 ml |
| Article number | ØD | Ød | D3 | height | Volume |
| 202-56020-0250 | 20 mm | 17 mm | 11 mm | 25 mm | 4 ml |
| 202-56060-0650 | 60 mm | 53 mm | 30 mm | 65 mm | 76 ml |
| 202-56065-1000 | 65 mm | 55 mm | 32 mm | 100 mm | 150 ml |
| 202-56073-0900 | 73 mm | 67 mm | 35 mm | 90 mm | 190 ml |
| 202-56085-1001 | 85 mm | 78 mm | 35 mm | 100 mm | 350 ml |
| 202-56100-1200 | 100 mm | 91 mm | 50 mm | 120 mm | 500 ml |
Wide conical crucibles
Ceramic crucibles in conical wide shape are highly temperature and corrosion resistant.
Our standard product range
| Article number | ØD | Ød | D3 | height | Volume |
| 203-11025-0200 | 25 mm | 22 mm | 13 mm | 20 mm | 4 ml |
| 203-11030-0240 | 30 mm | 26 mm | 15 mm | 24 mm | 6.5 ml |
| 203-11040-0320 | 40 mm | 36 mm | 20 mm | 32 mm | 16 ml |
| 203-11043-0370 | 43 mm | 38 mm | 22 mm | 37 mm | 22 ml |
| 203-11050-0400 | 50 mm | 45 mm | 25 mm | 40 mm | 34 ml |
| 203-11065-0550 | 65 mm | 59 mm | 33 mm | 55 mm | 88 ml |
| 203-11088-0600 | 88 mm | 80 mm | 44 mm | 60 mm | 170 ml |
Tubular crucibles
Tubular crucibles made of DEGUSSIT oxide ceramics guarantee precise measurement results as they do not show any outgassing or chemical reactions with the sample material.
Our standard product range
| Article number | ØD | Ød | height | Volume |
| 204-11006-0300 | 6 mm | 3 mm | 30 mm | 0.2 ml |
| 204-11010-0800 | 10 mm | 6 mm | 80 mm | 2.3 ml |
| 204-11012-1000 | 12 mm | 8 mm | 100 mm | 5 ml |
| 204-11015-1000 | 15 mm | 10 mm | 100 mm | 8 ml |
Attachable crucibles (volume approx. 3.5 ml)
Crucibles made of alumina ceramics do not react chemically with the sample material thus ensuring precise measurement.
Our standard product range
| Article number | Volume |
| 209-11000-0064 | 3.5 ml |
Attachable crucibles (volume approx. 0.2 ml)
Slip-on crucibles improve the sensitivity towards minimal temperature changes thanks to the high thermal conductivity of DEGUSSIT materials.
Our standard product range
| Article number | Volume |
| 209-11000-0068 | 0.2 ml |
Boats
Ceramic boats made of alumina can be used for high-temperature treatment of materials thanks to their excellent high-temperature properties.
Our standard product range
| Article number | L | W | height | Wall thickness | Volume |
| 221-11032-0090 | 32 mm | 9 mm | 6 mm | 2 mm | 0.2 ml |
| 221-11048-0090 | 48 mm | 9 mm | 6 mm | 2 mm | 0.4 ml |
| 221-11050-0150 | 50 mm | 15 mm | 8 mm | 2.5 mm | 1 ml |
| 221-11058-0230 | 58 mm | 23 mm | 13 mm | 3 mm | 5.2 ml |
| 221-11069-0090 | 69 mm | 9 mm | 6 mm | 2 mm | 0.7 ml |
| 221-11087-0150 | 87 mm | 15 mm | 8 mm | 2.5 mm | 2.8 ml |
| 221-11092-0180 | 92 mm | 18 mm | 10 mm | 3 mm | 5.5 ml |
| 221-11092-0230 | 92 mm | 23 mm | 13 mm | 3 mm | 9.5 ml |
| 221-11102-0310 | 102 mm | 31 mm | 17 mm | 3 mm | 20 ml |
| 221-11112-0150 | 112 mm | 15 mm | 8 mm | 2.5 mm | 4.7 ml |
| 221-11118-0180 | 118 mm | 18 mm | 10 mm | 3 mm | 7 ml |
| 221-11124-0230 | 124 mm | 23 mm | 13 mm | 3 mm | 13.5 ml |
| 221-11130-0310 | 130 mm | 31 mm | 17 mm | 3 mm | 27 ml |
Combustion trays
Combustion trays made of advanced ceramics are characterised by their high dimensional accuracy.
Our standard product range
| Article number | L | W | height | Wall thickness | Volume |
| 222-11050-0250 | 50 mm | 25 mm | 20 mm | 3 mm | 12 ml |
| 222-11050-0500 | 50 mm | 50 mm | 20 mm | 3 mm | 26 ml |
| 222-11075-0500 | 75 mm | 50 mm | 20 mm | 4 mm | 35 ml |
| 222-11100-0500 | 100 mm | 50 mm | 30 mm | 4 mm | 95 ml |
| Article number | L | W | height | Wall thickness | Volume |
| 222-21145-0850 | 145 mm | 85 mm | 30 mm | 5 mm | 212 ml |
| Article number | L | W | height | Wall thickness | Volume |
| 222-22205-1250 | 205 mm | 125 mm | 50 mm | 10-15 mm | 660 ml |
| Article number | L | W | height | Wall thickness | Volume |
| 222-56050-0250 | 50 mm | 25 mm | 20 mm | 3 mm | 12 ml |
| 222-56050-0500 | 50 mm | 50 mm | 20 mm | 3 mm | 26 ml |
| 222-56075-0500 | 75 mm | 50 mm | 20 mm | 4 mm | 35 ml |
| 222-56100-0500 | 100 mm | 50 mm | 30 mm | 4 mm | 95 ml |
